Masterpiece Opus Two
Masterpiece Opus Two Masterpiece // Speakers Description More details to follow! Price£10000 Enquire About product Gallery Specifications Gallery Specifications Technology Scandinavian Birch ply laminated and braced construction. Description 2 way, linear phase, twin 6″ Purifi passive radiator Drive Units 1 x 176mm Purifi Audio aluminium cone bass/midrange unit 1 x High precision Raal Ribbon tweeter Frequency Response 35Hz to 40KHz +/- 2dB on axis Impedance 4 ohms nominal Sensitivity 86dB spl at 1 metre on axis. 2.83V input Crossover 2nd order bass roll-off 2nd order tweeter Power Handling 400W peak un-clipped programme Dimensions 460h x 220w x 350d Weight 18kg Finishes Bespoke options available on request
Masterpiece HA2 Headphone Amplifier
Masterpiece HA2 Headphone Amplifier Amplifiers // Masterpiece Description Details to follow! Price£6000 Enquire About product Gallery Specifications Gallery Specifications Output Power 8W x 2 RMS 8 ohms Class of Operation Class A Minimum Load 4 ohms Frequency Response and Distortion 10Hz to 50kHz @ < 0.1% Signal to Noise Ratio 90dB Output Impedance 1.9 – 2.4 ohms Peak Output Current 6 amperes Damping Factor >8
Masterpiece HA1 Headphone Amplifier
Masterpiece HA1 Headphone Amplifier Amplifiers // Masterpiece Description Details to follow! Price£4000 Enquire About product Gallery Specifications Gallery Specifications Output Power 1W x 2 RMS 8 ohms Class of Operation Class A Minimum Load 4 ohms Frequency Response and Distortion 10Hz to 50kHz @ 0.02% Signal to Noise Ratio 90dB Output Impedance 1.5 mohms Peak Output Current 1 amperes Damping Factor >24 CMRR 71dB Power Consumption 250W Input Voltage 240V/50Hz Output Connectors Neutrik silver plated 6.3mm Jack and xlr Input Connectors Un-Balanced RCA Input Impedance 47 kohms Size 280w x 420d x 200h (mm) Weight 15kg
Masterpiece Class A Stereo Power Amplifier
Masterpiece Class A Stereo Power Amplifier Amplifiers // Masterpiece Description Details to follow! Price£4000 Enquire About product Gallery Specifications Gallery Specifications Output Power 95W x 2 RMS 4 ohms 50W x 2 RMS 8 ohms Class of Operation Class A Minimum Load 4 ohms Frequency Response and Distortion 10Hz to 30kHz @ 0.015% Signal to Noise Ratio 110dB Output Impedance 1.5 mohms Peak Output Current 6 amperes Damping Factor >100 CMRR 71dB Power Consumption 350W Input Voltage 240V/50Hz Output Connectors Rhodium plated binding posts Input Connectors Un-Balanced RCA Input Impedance 47 kohms Size 435w x 360d x 170h (mm) Weight 18kg
Masterpiece Edition MV3
Masterpiece Edition Pre-Amplifier Masterpiece // Pre-Amplifiers Description Our latest Masterpiece edition MV3 elevates the current high standard of tube pre-amplifiers with a design that uses Mundorf silver/gold in oil signal capacitors and Amtrak’s carbon film resistors in the signal path. High specification power supply capacitors, silver internal wiring and selected NOS vintage tubes bring added soundstage and reality to recordings. MV3 follows in the footsteps of the incredible MV2 using the same principles of minimum of active parts and high quality passive components in the signal path. A no compromise design and attention to components and internal wiring brings a product worthy of the Robson brand and a great match to our range of power amplifiers. MV3 features Blue Alps Swiss volume control Low ripple power supply on the anode Vintage tubes Duelund Coherent internal wiring Masterpiece edition with upgraded signal capacitors and resistors Great design and the use of very high quality components has created a pre-amplifier of exceptional abilities and able to drive the most difficult of power amplifier loads to below 10Kohms. Price£3600 Enquire About product Gallery Specifications Gallery Specifications Vacuum Tube Compliment Selected and matched vintage 12AX7 tubes Input Impedance 100 Kohm Inputs Unbalanced Output Unbalanced Frequency Bandwith 10Hz – 45KHz S/N Ratio 89dB Dimensions 240w x 370d x 160h (mm) Weight 8kg
Masterpiece Edition Pre-Amplifier
Masterpiece Edition Pre-Amplifier Masterpiece // Pre-Amplifiers Description Designed around the MV2 Pre-Amplifier but taken to a completely new level in terms of component specification, vacuum tube choice and internal wiring to give an even better sense of musical involvement and resolution. The Masterpiece Edition Pre-Amplifier has an extremely simple and pure signal path with only 1 output capacitor and 1 shunt resistor on the Khuzmo stepped attenuator which have been replaced with the incredible V-cap CuTF reference capacitor and a Charcroft Z foil resistor. This along with 5N solid silver and FEP fluoropolymer signal wiring gives this Pre-Amplifier added realism and an even better 3D soundstage capable of competing with the very best equipment in the world. The choice of Linlai Global Elite vacuum tubes also elevated the sound field beyond the previous Black Treasure tubes. Design specifications include dual mono power supplies with each channel supplied by it’s own high voltage and filament rails via a tube rectifier and feeding separate regulators to give incredible stereo separation. Bespoke designs available on request. A very simple but pure signal path based around the 6SN7 audio tube and using a single output capacitor which can be specifically chosen for it’s integration to solid state or valve amplifiers based on input impedance compatibility. Masterpiece Edition Pre-amplifier features: Dual mono design Lineal Global Elite vacuum tubes Khuzmo 48 way stepped shunt attenuator with Charcroft Z foil shunt resistor Ohno Continuous Cast unicrystal silver 5N wire internal wiring V-Cap CuTF output capacitors Purity of signal path is critical in the design of any amplifier to give incredibly black backgrounds and the retrieval and portrayal of the tiniest musical passages and notes. Price£6000 Enquire About product Gallery Specifications Gallery Specifications Vacuum Tube Compliment 4 x Linlai Global Elite E-6SN7 matched pairs 1 x Philips 5Y3 Rectifier tube Input Impedance 47 kohm Output Impedance 150 ohms Inputs Balanced XLR pair and RCA unbalanced pair line inputs Rhodium plated Output Balanced XLR pair and RCA unbalanced pair Line inputs Rhodium plated Frequency Response 10Hz – 50KHz Power Consumption 50VA Gain 22dB THD 0.3% 1Khz / 4Vef S/N Ratio 90dB Dimensions 440w x 370d x 185h (mm) without tubes Weight 22kg
Masterpiece Regis
Masterpiece Regis Masterpiece // Speakers Description After many years of building the hugely popular and successful Regis Mk1 and knowing that due to the discontinued bass/mid driver, I would have to design a new model and try and succeed in raising the bar in terms of overall sonic qualities. No mean feat because the Mk1 is truly a reference loudspeaker in many ways. The Regis Masterpiece was born from the desire to build a cost no object reference stand mount loudspeaker and choosing 2 very high end drive units from well respected manufacturers, namely Morel and Raal. The top of the range Morel copper sleeve bass/mid driver is exceptional in every way and the Raal ribbon tweeter is possibly the best tweeter in existence and also used in the Voltaire lll and new Opus One. Internal wiring, cross-over components and Rhodium plated pole connectors are chosen specifically to match these particular drive units and honed to match this design perfectly. Complimented with Mundorf’s “Angel hair” internal wadding for damping properties which significantly increase the auditory spaciousness of music reproduction. These loudspeakers are capable of the most incredible holographic presentation, high resolution detail and bass depth defying their size. These reference monitors will continue to extract more resolution and quality no matter how good the ancillary equipment is in terms of cost or quality. Price£6000 Enquire About product Gallery Specifications Gallery Specifications Technology Finnish Birch Ply and MDF matrix construction Description 2 way, linear phase, Infinite baffle enclosure Drive Units 1 x Morel 160 mm damped polymer composite cone bass/mid range unit 1 x Raal precision Ribbon Tweeter Frequency Response 40Hz to 40KHz +/- 2dB on axis Impedance 8 ohms nominal, 5 ohms minimum Sensitivity 87dB spl at 1 metre on axis. 2.83V inputt Crossover 2nd order bass roll-off 2nd order tweeter Power Handling 150W peak un-clipped programme Dimensions 380h x 200w x 320d (mm) Weight 9kg Finishes Standard finishes available American Black Walnut and black parchment hide. Bespoke options available in various hides and hardwood. Mundorf capacitor, Inductor and Cryo treated internal wiring as standard.
Masterpiece Opus One
Masterpiece Opus One Masterpiece // Speakers Description With Opus One, we are proud to share our newly designed flagship loudspeaker. Many years of collaboration with Purifi Audio’s legendary drive units coupled with a Real precision ribbon tweeter has enabled a significant quantum step up from everything we have built before. Opus One establishes new benchmarks in musicality, transparency, and fidelity along with testing our limits of dynamic speaker design with a constellation of exotic technologies, techniques and materials. Expressed in immaculate execution in every little detail from distressed hides and exotic hardwoods to engraved panels and de-coupled to the rest of the world via an isolation platform. A timeless piece of art in your living environment ready to engage the soul with a beautiful portrayal of musical expression and to create something unique in balance between art, craftsmanship, technology and performance. The combination of Purifi Audio Ushindi technology bass/mid motors and the Raal ribbon tweeter are able to employ lightning-fast precision and deliver exquisite whisper-quiet musical passages or thunderous bass completely free of distorting cabinet resonances. Dual 8″ passive radiators tuned to the cabinet volume offer the perfect way of enhancing bass energy without the inherent problems with ports or transmission lines. Cabinet construction begins with an inert baffle of 50mm thickness and employing a fully braced design througout. Often the biggest problem with loudspeaker design is its inability to decouple itself from the floor and also other extraneous airborne vibrations. The perfect solution was an existing design which has already won many awards in its own right and able to completely remove the passage of deleterious vibrations both to and from the speaker cabinets. This impart a serious improvement in soundstage and bass precision. For those wishing to experience the visceral thrill and lyricism of the best loudspeakers in the world should audition Opus One. Price£26000 Enquire About product Gallery Specifications Gallery Specifications Technology Scandinavian Birch ply laminated and braced construction.Townshend Podium Platforms Description 2 way, linear phase, twin 8″ Purifi passive radiator Drive Units 2 x 176mm Purifi Audio aluminium cone bass/midrange unit 1 x High precision Raal Ribbon tweeter Frequency Response 29Hz to 40KHz +/- 2dB on axis Impedance 4 ohms nominal Sensitivity 88dB spl at 1 metre on axis. 2.83V input Crossover 2nd order bass roll-off 2nd order tweeter Power Handling 400W peak un-clipped programme Dimensions 1200h x 22w x 42d (cm) Weight 35kg Finishes Bespoke options available on request
Masterpiece Phono Stage
Masterpiece Phono Stage Masterpiece // Phono Stage Description The Masterpiece Phono stage uses an existing incredible design and applies the same level of component, internal wiring, tube and connector upgrades which only applies to the Masterpiece collection for the connoisseurs of high end hifi. Both the Masterpiece Pre-amplifier and Phono stage use simple signal path topology where every signal component is chosen for it’s absolute quality and construction. Internal wiring uses the same ultra high purity silver wire as used in the Ref interconnect cables. Signal capacitors are replaced with V-caps CuTF Reference grade units and resistors with Charcroft Z foil. Rhodium plated connectors and power inlet socket are standard. Power supply capacitors are the excellent Mundorf tube caps for ultimate power supply delivery and all pub’s are mounted for micro vibration absorption and dissipation. Vacuum tubes are also dampened. Masterpiece Edition Phonostage features : Charcroft Z foil resistors in the critical signal path for low noise and a more natural sound. V-Cap CuTF signal path capacitors. Lundahl MC step up transformers (SUT) using amorphous cobalt core and dual coil structure with Cardas high purity wire. Silver internal wiring and Rhodium plated RCA connectors Toroidal transformers with B+ regulators for low PSRR figures. High amplification, super accurate RIAA EQ , low output impedance and low distortion. All cabinet construction is made with exotic hardwoods and a copper top panel with additional damping. Available with built in Lundahl amorphous core SUT’s for MC cartridges or as a seperate custom built SUT in Bolivian rosewood or other exotic hardwood. Price£5000 Enquire About product Gallery Specifications Gallery Specifications Input MM (RCA) – 47k MC (RCA) – adjustable input impedance Frequency Response +/- 0.6dB over RIAA Curve Gain MM – 52dB MC – 70dB using Lundahl amorphous core transformers Noise -82dB Input Impedance 47k Output Impedance 450 ohms Overload 3.3mV in Power Supply B+ regulators PSRR by 60dB Low noise toroidal transformers Vacuum Tube Complement 12X4 Rectifier tube and 4 x 6922 tubes Dimensions 440w x 370d x 185h (mm) Weight 20kg
Masterpiece Edition Turntable
Masterpiece Edition Turntable Masterpiece // Turntable Description Another exciting project and product development is based around the well known Swiss made Lenco turntable which fundamentally is constructed extremely well with a precision motor and structure that lends itself to be upgraded and modified to create an incredibly good turntable. The initial phase involves a complete strip down of every component with certain key parts replaced or modified. The main chassis is resprayed and lacquered before re-assembly and lubricated for longevity and noise reduction. Because the central spindle and platter are already of a very high standard and tolerance, these are polished and retained. The main bearing is either replaced with an upgraded bearing or modified with a new ruby ball bearing and thrust plate. The main motor is stripped down and inspected for wear or noise, re-assembled and lubricated. I have yet to find a motor which has failed these tests or brought back to a new standard. The high mass plinth is a based around the natural qualities of certain hardwoods and their abilities to exhibit very high levels of resonance and damping control as well as high density and other acoustic characteristics.. This model is made from solid sections of Bubinga hardwood which is incredibly heavy and dense, perfect for reducing micro vibrations within the motor and main turntable structure. This combined with Tungsten carbide ball bearings on Panzerholz dampening feet ensure the combined structure of the turntable is virtually free from extraneous effects and vibrations. A choice of tonearm boards made from either the same hardwood or Panzerholtz is available with additional dampening and specifically chosen for their acoustic characteristics and density. Days of sanding and preparation are done prior to a high gloss lacquer finish with further wet sanding, buffing and final polishing before final assembly and soak testing. A choice of tonearm is also available and from SME, Ikea and Reed along with a select number of cartridges from Phasemation of Japan. Please get in touch to discuss this product. Price £4000 without arm and cartridge Enquire About product Gallery Gallery
